Elevator Push Button 5400 LOP COP Call Buttons Applicable to Elevator Parts with TNT Transportion

1. Key Features & Specifications

① Physical Design

• Material:

  • Faceplate: Stainless steel or brushed aluminum (anti-corrosion).

  • Button Caps: Polycarbonate (scratch-resistant, UV-stable).

• Mounting:

  • Surface-mounted or flush-mounted (depending on cab design).

  • Standard cutout: 22mm–25mm diameter (varies by button type).

• Finish Options:

  • Brushed metal, matte black, or custom colors (for aesthetic integration).

② Electrical & Functional Specs

• Button Type:

  • Momentary push-button (normally open contact).

  • Illuminated LED (white, red, or green backlight).

• Voltage Rating: 24V DC (low-voltage operation for safety).

• Contact Rating: 1A @ 30V DC (sufficient for elevator control signals).

• Tactile Feedback: Audible "click" or silent operation (configurable).

③ Compliance & Durability

• IP Rating: IP54 (dust and splash-proof).

• Fire Safety: Meets EN 81-70 (fire-resistant materials).

• Cycle Life: ≥500,000 presses (long-lasting reliability).

2. Common Button Types in Schindler 5400 Series

3. Installation & Compatibility

• Compatible Controllers:

  • Schindler Miconic 10 / Miconic TX / PORT systems.

• Wiring:

  • Uses ribbon cable or terminal block connections.

  • Plug-and-play with Schindler’s modular cab panels.

4. Troubleshooting & Maintenance

Common Issues

• Button unresponsive → Check wiring or LED power supply.

• LED flickering → Loose connection or failing backlight.

• Stuck button → Debris in mechanism (clean with compressed air).

Replacement Notes

• Ensure Schindler 5400-compatible part numbers (e.g., A12345-001).

• Buttons are field-replaceable without full panel removal.
