Sulab Rubber V Belt Toothed Transmission Belt XPZ1420/3VX560 XPZ1412/3VX560

Highlight

Sulab Rubber V belt XPZ1420
,
Toothed Transmission Belt XPZ1420
,
Toothed Transmission Belt 3VX560
Brand

Sulab
Description

Escalator Parts
Model

XPZ1420/3VX560
MOQ

1PC
Transportion

TNT, UPS, DHL, Fedex, Air, Sea
Applicable

Elevator
Packages

Carton, Wooden Case, Pallet Etc
Delivery Time

Normally 2-3 Working Days After Payment
Warranty

One Year
Payment Method

Company Bank, Western Union, Alibaba, Paypal Etc
Brand Name

Sulab
Model Number

XPZ1420/3VX560
Minimum Order Quantity

1
Delivery Time

2-3 working days
Payment Terms

T/T,Western Union,MoneyGram

Sulab Rubber V Belt Toothed Transmission Belt XPZ1420/3VX560 XPZ1412/3VX560

Name: Sulab Rubber V Belt Toothed Transmission Belt XPZ1420/3VX560 XPZ1412/3VX560
Brand: Xian Sulab Machinery Co., Ltd.
SKU: XPZ1420/3VX560
Availability: InStock

button button

Get Price Contact Now

Sulab Rubber V-belt Toothed Transmission Belt XPZ1420/3VX560 XPZ1412/3VX560

Based on the provided model "XPZ1420/3VX560", here is a detailed analysis and description by breaking down the possible components and referring to similar product specifications:

1. Model Parsing and Possible Product Category

XPZ1420:
The "XPZ" prefix is commonly used in V-belt (V-belt) specifications. For example, in the European standard (ISO 4184), V-belts are classified into XPZ, XPA, XPB, XPC, etc., where "XPZ" represents the smallest cross-sectional size in the extra-light duty series. The number "1420" likely indicates the effective length of the belt in millimeters (mm), i.e., the effective circumference of the belt is approximately 1420 mm.
3VX560:
The "3VX" may correspond to the American standard (RMA/ISO 1082) V-belt series, where "3V" denotes the cross-sectional type (similar to the European XPZ in size but with different naming conventions), and "560" typically represents the nominal length in inches (in). Converting 560 inches to millimeters: 1 inch ≈ 25.4 mm, so 560 × 25.4 ≈ 1422.4 mm, which is close to the 1420 mm in "XPZ1420", suggesting that the two may be equivalent specifications under different standards.

Conclusion: This model likely refers to a V-belt used in mechanical power transmission systems, with "XPZ1420" and "3VX560" representing its specifications under European and American standards, respectively.

Brand	Sulab
Description	Escalator parts
Model	XPZ1420/3VX560
MOQ	1PC
Transportion	TNT, UPS, DHL, Fedex, Air, Sea
Applicable	Elevator
Packages	Carton, Wooden case, Pallet etc
Delivery Time	Normally 2-3 working days after payment
Warranty	One year
Payment Method	Company Bank, Western union, alibaba, Paypal etc

2. Detailed Technical Parameters and Application Scenarios

(1) Technical Parameters

Parameter	Description
Cross-sectional Type	- XPZ (European standard): Trapezoidal cross-section, top width ~8.5 mm, height ~5.5 mm. - 3VX (American standard): Similar to XPZ, top width ~9.5 mm, height ~6 mm.
Effective Length	- XPZ1420: Effective circumference ≈1420 mm. - 3VX560: Nominal length ≈560 in (≈1422.4 mm), with the actual effective length slightly shorter due to standard differences.
Power Transmission Capacity	Suitable for transmitting small to medium power, typically used in low-speed to medium-speed drives (rotational speed ≤4000 rpm).
Tensile Strength	Made of rubber, fabric, and tensile cords (such as aramid or polyester), with a breaking strength of ~500-800 N (specific values depend on the manufacturer).

(2) Application Scenarios

Industrial Machinery: Used in conveyors, fans, pumps, compressors, and other equipment that require belt-driven power transmission.
Household Appliances: Such as washing machines, air conditioners, or small mechanical devices (though industrial applications are more common).
Automotive Accessories: Occasionally used in auxiliary systems of vehicles (e.g., generator or air conditioning compressor drives), but automotive belts often have different standards (e.g., "PK" series).

3. Purchase and Replacement Considerations

Compatibility:
- Ensure the pulley groove matches the belt cross-section (e.g., an XPZ belt requires an XPZ-compatible pulley).
- Check the center distance and tensioning mechanism of the drive system to avoid issues like slippage or excessive wear caused by incorrect length.
Brand and Quality:
Well-known manufacturers include Gates, ContiTech, Mitsuboshi, etc. High-quality belts offer better heat resistance, wear resistance, and service life (typically 1-3 years under normal conditions).
