SIGMA IPM-RLA REV1.2 MMR Elevator IGBT Drive Board with PM50RLA120 / PM75RLA120 Core for Ultra-Low Stray-Inductance and On-Board Gate-Drive Redundancy
-
Highlight
PM50RLA120 / PM75RLA120 Core IGBT Drive Board
,Ultra-Low Stray-Inductance Elevator Drive Board
,On-Board Gate-Drive Redundancy MMR Drive Board
-
TypeIPM-RLA REV1.2
-
Product NameSIGMA IPM-RLA REV1.2
-
ApplicableElevator Parts,Elevator Equipment,General For Escalator Parts,Passenger Lift,Passenger Elevator
-
Transportation ModeAir,FedEx TNT DHL,FOB,EMS Or UPS) /LCL By Sea Or Train,FedEx
-
Business TypeManufacturer
-
PackingMPacked In Carton
-
Brand NameSIGMA
-
Model NumberIPM-RLA REV1.2
-
Minimum Order Quantity1
-
Delivery Time3-5 Working Days
-
Payment TermsD/A,D/P,T/T,Western Union
SIGMA IPM-RLA REV1.2 MMR Elevator IGBT Drive Board with PM50RLA120 / PM75RLA120 Core for Ultra-Low Stray-Inductance and On-Board Gate-Drive Redundancy
SIGMA IPM-RLA REV1.2 MMR Elevator IGBT Drive Board (PM50/75RLA120 Core)
The SIGMA IPM-RLA REV1.2 drive board serves as the central component of the MMR-series elevator inverter. Engineered around the intelligent PM50RLA120 / PM75RLA120 IGBT module, this board provides ultra-low stray-inductance power paths and integrated gate-drive redundancy, significantly reducing dynamic losses and preventing jitter-induced shutdowns. Designed as a plug-and-play solution compatible with original LG-Sigma harnesses, it supports elevator capacities ranging from 6-person to 30-person lifts without requiring hardware modifications.
Key Advantages
- 100% drop-in replacement—no cabinet wiring modifications required
- Conformal-coated PCB ensures reliable operation in 60°C ambient conditions
- 1-year warranty with CE & RoHS compliance certification
| Model | IPM-RLA REV1.2 |
| Core module | PM50RLA120 (50 A 1200 V) or PM75RLA120 (75 A 1200 V) |
| Switching frequency | 2 - 8 kHz (default 4 kHz) |
| Supply voltage | 15 VDC ±5% (on-board derived) |
| Peak gate current | ±6 A per IGBT |
| Isolation | 2.5 kV RMS opto-couplers |
| Operating temperature | -10°C to +60°C |
| Humidity | ≤ 95% RH non-condensing |
| PCB size | 200 mm × 120 mm × 1.6 mm |
| Mounting | 4 × Ø4.2 mm slots on 190 mm × 110 mm |
| Weight | 0.32 kg |
| Protection | Over-current, under-voltage, over-temperature (via NTC) |
Packaging & Warranty
Individual units are packaged in anti-static boxes; bulk orders ship in cartons of 20 units. Includes 12-month functional warranty from the date of dispatch.
Order today to maintain optimal elevator performance with smoother operation, reduced heat generation, and extended service life.
