Semikron SKiiP 36NAB126V1 Intelligent IGBT Module 1200 V 70 A 18.5 kW MiniSKiiP 3 for Elevator Drives
-
Highlight
1200 V IGBT Module
,70 A Intelligent Power Module
,18.5 kW MiniSKiiP 3
-
Type36NAB126V1
-
Product NameSemikron SKiiP 36NAB126V1 Intelligent IGBT Module
-
ApplicableElevator Parts,Elevator Equipment,General For Escalator Parts,Passenger Lift,Passenger Elevator
-
TransportationClients' Requestment,DHL TNT FEDEX UPS,Sea Delivery
-
Business TypeManufacturer
-
PackingPacked In Carton
-
Model Number36NAB126V1
-
Minimum Order Quantity1
-
Delivery Time3-5 Working Days
-
Payment TermsD/A,D/P,T/T,Western Union
Semikron SKiiP 36NAB126V1 Intelligent IGBT Module 1200 V 70 A 18.5 kW MiniSKiiP 3 for Elevator Drives
Semikron SKiiP 36NAB126V1 Intelligent IGBT Module 1200 V 70 A 18.5 kW MiniSKiiP 3
Ready-to-mount intelligent power module combining a 1200 V / 70 A three-phase IGBT 3 (Trench) bridge, soft CAL freewheeling diodes and an integrated gate driver on a single MiniSKiiP 3 PCB-mount substrate.
Key Features
- Spring-contact technology eliminates solder joints, increases vibration resistance and halves assembly time
- Ideal for 18.5 kW motor drives, solar/UPS inverters and high-frequency power converters
- UL-recognised (file E63532), thermally optimised 82 × 59 × 16 mm package
- Fits standard MiniSKiiP heatsinks with press-fit or screw mounting in seconds
- Drop-in replacement for SKiiP 36NAB126V1-M01 / -M20 variants
- Backward-compatible with existing gate-drive and snubber layouts
Technical Specifications
| Part Number | SKiiP 36NAB126V1 |
|---|---|
| Manufacturer | Semikron-Danfoss |
| Chip Technology | IGBT 3 Trench + CAL diode |
| VCES | 1200 V |
| IC cont / ICRM | 70 A / 350 A (10 ms) |
| Pout (typ.) | 18.5 kW |
| Topology | 3-phase bridge (CIB) |
| Integrated Driver | Yes, full-bridge gate drive |
| Isolation | 2.5 kV RMS ceramic substrate |
| Supply Voltage | 15 V (logic) |
| Switching Frequency | ≤ 20 kHz |
| Operating Temperature | -40 °C … +125 °C (Tj) |
| Dimensions | 82 mm × 59 mm × 16 mm |
| Mounting | Press-fit or M3 screws |
| Weight | 162 g |
| Approvals | UL E63532, RoHS |
This intelligent power module is designed for high-reliability industrial applications requiring robust performance and quick installation.
