High Voltage Strip TPI-02-0104 TPI-02-0104-K2 TPI-02-0609 E229877 TPL-06-5003

High-voltage Strip TPI-02-0104 TPI-02-0104-K2 TPI-02-0609 E229877 TPL-06-5003

Basic Parameters

• Input Voltage: 10 - 13.2V, which enables it to work stably within a certain voltage range and adapt to different power supply conditions.
• Output Power: 18W, providing stable power support for connected load devices.
• Output Voltage: 12V, supplying a suitable working voltage for components such as the backlight tubes of LCDs.
• Transistor Connection Mode: Single - ended type, which has the advantages of simple circuit structure and low cost.
• Modulation Mode: Pulse Width Modulation (PWM) mode. It controls the output voltage and power by adjusting the pulse width, featuring high efficiency and stability.

Functional Roles

• Voltage Conversion: It converts the input lower DC voltage into the higher AC voltage required by the backlight tubes of LCDs. Generally, it can convert the 10 - 13.2V DC voltage into a high voltage (such as several thousand volts of AC voltage) sufficient to light up the backlight tubes.
• Brightness Adjustment: Through the PWM modulation mode, it can adjust the duty cycle of the output voltage as needed, so as to realize the adjustment of the brightness of the backlight tubes and meet the needs of different display scenarios.
• Protection Functions: It is equipped with multiple protection functions, such as overvoltage protection, overcurrent protection, short - circuit protection, etc. When the output voltage is too high, the current is too large, or a short - circuit fault occurs, it can automatically cut off the power supply or take other protection measures to prevent the backlight tubes and other circuit components from being damaged.

Application Fields

• Liquid Crystal Displays: It is widely used in various sizes of liquid crystal displays, such as computer monitors, LCD TVs, tablet computers, etc., providing power for their backlight tubes to enable the screens to display images normally.
• Industrial Control: It is also applied in equipment such as human - machine interfaces and touch screen displays in the field of industrial control, providing stable backlight power for the liquid crystal displays of these devices.
• Medical Equipment: The liquid crystal displays of some medical equipment such as monitors and B - ultrasounds will also use the TPI - 02 - 0104 high - voltage strip to ensure the normal display and use of the equipment.
