Hyundai Elevator Car Top Panel Control Board with STM32 Microprocessor 24V DC Input and Rev1.4 Optimization

Brand Name: Hyundai
Model Number: SAF20400506 Rev1.4
Minimum Order Quantity: 1
Delivery Time: 2-3 working days
Payment Terms: T/T,Western Union,
Inquiry Now
Get A Quote
Specifications
Highlight Features

Rev1.4 Elevator Car Top Panel

,

STM32 Microprocessor Elevator Control Board

,

24V DC Input Elevator PCB

Brand:
Hyundai
Description:
Elevator Board
Model:
SAF20400506 Rev1.4
MOQ:
1PC
Transportion:
TNT, UPS, DHL, Fedex, Air, Sea
Packages:
Carton, Wooden Case, Pallet Etc
Delivery Time:
Normally 2-3 Working Days After Payment
Payment Method:
Company Bank, Western Union, Alibaba, Paypal Etc
Product Description
Shanghai Hyundai Elevator Car Top Panel SAF.20400506, REV1.6/1.4
This brand new, original control board serves as a crucial system component in Shanghai Hyundai elevator systems. The printed circuit board features green solder mask construction with revision designation Rev 1.4, indicating an engineered and optimized version.
Brand Hyundai
Description Elevator board
Model SAF20400506 Rev1.4
MOQ 1PC
Transportation TNT, UPS, DHL, Fedex, Air, Sea
Packages Carton, Wooden case, Pallet etc
Delivery Time Normally 2-3 working days after payment
Warranty One year
Payment Method Company Bank, Western union, alibaba, Paypal etc
Technical Features
  • Integrated STM32 series 32-bit ARM architecture microprocessor as main control unit
  • Winbond SPI Flash memory for program storage
  • ADI differential signal receivers for encoder signal processing
  • Dual CAN bus architecture (utilizing TJA1050 transceivers) for data exchange
  • RS-485 interface capability for elevator group control communication
  • Power supply section employs LM2576 switching voltage regulators
  • Supports 24V DC wide voltage input
  • Onboard array of SMD LED status indicators for operational feedback
  • Certified to CE and CCC standards
  • Operating temperature range of -25℃ to +70℃
This board is primarily implemented for critical functions including car control, operation scheduling, and safety monitoring in Hyundai elevator systems, where its reliable performance has established it as a standard configuration across multiple elevator models.

Elevator PCB Board - FAQ

Q1: How do I identify the correct replacement elevator PCB board?
To identify a replacement elevator PCB board, check the original part number, hardware revision, board markings, and elevator controller model. Clear photos of both sides of the PCB can help distinguish different versions.

Q2: Can elevator PCB boards with similar part numbers be interchangeable?
Not necessarily. Elevator PCB boards with similar part numbers may differ in hardware revisions, firmware, connector layouts, or communication protocols. Compatibility must be verified against the existing elevator system.

Q3: Does a replacement elevator PCB board require programming?
Some replacement PCB boards require firmware configuration, parameter settings, or system-specific programming. Others may already contain the required software. The correct procedure depends on the PCB model and its role in the elevator control system.

Q4: Can a faulty elevator PCB board be replaced without changing the complete control system?
In some cases, an individual PCB can be replaced if the replacement is compatible with the existing controller, firmware, wiring, and connected components. A qualified technician should confirm the fault before deciding on replacement.

Q5: What information should I provide when sourcing a replacement elevator PCB board?
Please provide the original PCB part number, hardware revision, elevator model, clear board photos, and required quantity. SULAB can help review these details and check available replacement options.
