Genuine OTIS GAA24350BP1 AT120 Door Inverter VVVF Drive PCB with Plug-and-play and Sinusoidal PWM Control

Brand Name: OTIS
Model Number: GAA24350BP1 AT120
Minimum Order Quantity: 1
Delivery Time: 3-5 Working Days
Payment Terms: D/A,D/P,T/T,Western Union,
Inquiry Now
Get A Quote
Specifications
Highlight Features

Genuine OTIS Door Inverter

,

Plug-and-play VVVF Drive PCB

,

Sinusoidal PWM Elevator Door Operator

Type:
GAA24350BP1 AT120
Product Name:
GAA24350BP1 AT120 Door Inverter
Transportation:
Clients' Requestment,DHL TNT FEDEX UPS,Sea Delivery
Application:
Elevator Parts
Business Type:
Manufacturer
Keywords:
Elevator Parts,Elevator Safety ,GAA24350BP1 AT120 Door Inverter
Packing:
Packed In Carton
Product Description
GAA24350BP1 AT120 Door Inverter – Genuine OTIS Elevator Door Operator VVVF Drive PCB

The GAA24350BP1 is a brand-new, genuine OTIS AT120 door inverter board that delivers smooth, whisper-quiet VVVF control for OTIS AT120 door operators. Plug-and-play with existing wiring, it replaces failed drives in passenger elevators from 320 kg to 2,500 kg capacity and supports both side-opening and center-opening doors.

Technical Specifications
Part Number GAA24350BP1
Function Door operator VVVF inverter
Input Voltage 230 VAC ±10%, 50/60 Hz
Output Power 0.4 kW (max)
Control Mode Sinusoidal PWM, closed-loop vector
Protections Over-current, over-temp, short-circuit, encoder failure
Encoder Supply 5 V / 12 V optional
Operating Temperature -10°C to +55°C
Mounting Snap-in DIN rail or M4 standoffs
Dimensions 180 mm × 130 mm × 65 mm
Weight 0.7 kg
Certification CE, UL recognised, ISO 9001
Key Features
  • 100% OEM - identical footprint and connector layout
  • Flash firmware - field-updatable via OTIS service tool
  • Quiet start/stop - reduces door noise < 50 dB
  • Universal encoder port - supports TTL or resolver feedback
  • Stock ready - ships within 24 hours worldwide
Install only by certified technicians; verify encoder type before power-up.

Elevator PCB Board - FAQ

Q1: How do I identify the correct replacement elevator PCB board?
To identify a replacement elevator PCB board, check the original part number, hardware revision, board markings, and elevator controller model. Clear photos of both sides of the PCB can help distinguish different versions.

Q2: Can elevator PCB boards with similar part numbers be interchangeable?
Not necessarily. Elevator PCB boards with similar part numbers may differ in hardware revisions, firmware, connector layouts, or communication protocols. Compatibility must be verified against the existing elevator system.

Q3: Does a replacement elevator PCB board require programming?
Some replacement PCB boards require firmware configuration, parameter settings, or system-specific programming. Others may already contain the required software. The correct procedure depends on the PCB model and its role in the elevator control system.

Q4: Can a faulty elevator PCB board be replaced without changing the complete control system?
In some cases, an individual PCB can be replaced if the replacement is compatible with the existing controller, firmware, wiring, and connected components. A qualified technician should confirm the fault before deciding on replacement.

Q5: What information should I provide when sourcing a replacement elevator PCB board?
Please provide the original PCB part number, hardware revision, elevator model, clear board photos, and required quantity. SULAB can help review these details and check available replacement options.
