Schneider Electric Limit Switch with 1NO+1NC Snap-Action Contacts 10 Million Mechanical Cycles and IP65 Protection for Elevators
-
Highlight
1NO+1NC Snap-Action Contacts Limit Switch
,10 Million Mechanical Cycles Travel Switch
,IP65 Protection Elevator Switch
-
BrandSchneider
-
DescriptionElevator Switch
-
ModelXCKN2110P20C
-
MOQ1PC
-
TransportionTNT, UPS, DHL, Fedex, Air, Sea
-
PackagesCarton, Wooden Case, Pallet Etc
-
Delivery TimeNormally 2-3 Working Days After Payment
-
WarrantyOne Year
-
Payment MethodCompany Bank, Western Union, Alibaba, Paypal Etc
-
Brand NameSchneider
-
Model NumberXCKN2110P20C
-
Minimum Order Quantity1
-
Delivery Time2-3 working days
-
Payment TermsD/P,T/T,Western Union
Schneider Electric Limit Switch with 1NO+1NC Snap-Action Contacts 10 Million Mechanical Cycles and IP65 Protection for Elevators
Schneider Electric Limit Switch XCKN2110 2118 2145 2121 2102P20C
The Schneider Electric XCKN2110P20C is a standard limit/travel switch from the OsiSense XC series, specifically engineered for elevator safety systems. This robust switch is primarily used for hoistway upper/lower limit detection, landing/car door position monitoring, and safety circuit protection in elevators from leading brands including OTIS, Mitsubishi, KONE, and Thyssen.
Key Technical Specifications
- 1NO+1NC snap-action contacts (DPDT configuration)
- Rated voltage: AC240V/DC250V
- Rated current: 10A (AC15 240V 3A)
- Mechanical life: ≥10 million cycles
- Electrical life: ≥1 million cycles
- Operating force: 10-30N with 5mm stroke
- High-strength engineering plastic housing
- Protection class: IP65 rated
- Operating temperature range: -25°C to +80°C
- Installation: Bolt fixing (35mm DIN rail or direct mounting)
- Wiring: Screw clamp terminal with M20×1.5mm cable entry
- Certifications: CE, CCC, UL compliant with IEC 60947-5-1 standard
Product Details
| Brand | Schneider Electric |
| Description | Elevator Limit Switch |
| Model | XCKN2110P20C |
| Minimum Order Quantity | 1PC |
| Shipping Methods | TNT, UPS, DHL, Fedex, Air, Sea |
| Packaging Options | Carton, Wooden case, Pallet etc |
| Delivery Time | Normally 2-3 working days after payment |
| Warranty | One year |
| Payment Methods | Company Bank, Western union, Alibaba, Paypal etc |
Application & Operation
Installed at the top and bottom of elevator hoistways, this limit switch activates when the elevator car reaches its maximum travel limits. The switch triggers to cut off the safety circuit, preventing overtop or bottoming accidents. Featuring a spring return metal plunger design, the switch automatically resets to its initial state after activation, ensuring the elevator can be manually reset following emergency stops.
