Kone Elevator Avdmat2 Dot Matrix Display PCB Board KM863270G02

Details for Kone Elevator Avdmat2 Dot Matrix Display Pcb Board KM863270G02

Pictures for Kone Elevator Avdmat2 Dot Matrix Display Pcb Board KM863270G02

The first row of signal lights on the Giant KONE motherboard
1.Emergency alarm
On: Red, there is an alarm; Off: There is no alarm; Note: Reset by pressing the select /accept button;
2. Lift in fault
On: Red, error preventing normal operation; Off: Normal operation;
3.CPU running
On: Yellow, CPU is running; Off: CPU is not running Note: CPU is running when the LED is flashing;

Elevator PCB Board - FAQ

Q1: How do I identify the correct replacement elevator PCB board?
To identify a replacement elevator PCB board, check the original part number, hardware revision, board markings, and elevator controller model. Clear photos of both sides of the PCB can help distinguish different versions.

Q2: Can elevator PCB boards with similar part numbers be interchangeable?
Not necessarily. Elevator PCB boards with similar part numbers may differ in hardware revisions, firmware, connector layouts, or communication protocols. Compatibility must be verified against the existing elevator system.

Q3: Does a replacement elevator PCB board require programming?
Some replacement PCB boards require firmware configuration, parameter settings, or system-specific programming. Others may already contain the required software. The correct procedure depends on the PCB model and its role in the elevator control system.

Q4: Can a faulty elevator PCB board be replaced without changing the complete control system?
In some cases, an individual PCB can be replaced if the replacement is compatible with the existing controller, firmware, wiring, and connected components. A qualified technician should confirm the fault before deciding on replacement.

Q5: What information should I provide when sourcing a replacement elevator PCB board?
Please provide the original PCB part number, hardware revision, elevator model, clear board photos, and required quantity. SULAB can help review these details and check available replacement options.
